• Range : -1 ~ 400bar
  Gauge pressure        Absolute pressure
  0 ~ 1      0 ~ 20               -1 ~ 0 bar
  0 ~ 2      0 ~ 50               -1 ~ 1 bar
  0 ~ 3      0 ~ 100             -1 ~ 2 bar
  0 ~ 5      0 ~ 200             -1 ~ 5 bar
  0 ~ 10    0 ~ 400             -1 ~ 9 bar
  0 ~ 15                            -1 ~ 15 bar

• Power supply
  Nominal : 24VDC
  Supply current : max 300A
• Output signal
  Current output: 4~20mA STD
  Signal current Limited : max 23mA
• Output load R
  Output signal : Load limitation
  Current output : max 750 ohm (23mA)
• Display
  Digital : 3-Digit 7-segment LED
  Bar-graph : Bar-graph LED
• Alarm output
  Output contact : Hi & Low (normal open)
  Contact load max 1A 24VDC
• Accuracy
  Linearity    : < ±0.25% F.S.
  Hysteress : < ±0.25% F.S.
  Stability    : < ±1% F.S. / year
• Temperature effects
  Operating temp : Sensor : -20°C ~ +125°C
                            Transmitter : -20°C ~ +80°C
                            Display : -20°C ~ +80°C
• Maximum over pressure F.S.
  Proof pressure : 200% F.S.
  Burst pressure : 400% F.S.
• Material
  Housings : Dia casting aluminum
  Enclosure : Weather-proof (IP66)
  Pressure sensor : Silicon
  Wetted parts : 316L SS

主要用途：

1. (型号：BPT-100)
数码量表及开关压力传感器
2. (型号：BPT-200)
数码量表、开关及平面膜片压力传感器
3. (型号：BPT-300)
数码量表及开关
可防止腐蚀的压力传感器
4. (型号：BPT-400)
数码量表及开关金属或不锈钢法兰压力传感器
